Product Details

Waste timber grinder is an important equipment together with chipping and crushing function, mainly used in raw materials primary crushing, grinding process, for later better expanding process.

image001_

Raw Material

Wood pieces, straw, grass, stalk, tree branches, waste cardboard, bamboo, wood scrap, corn stalk, peanut shell, wheat stalk, wood fuel, cotton stalk, biomass shell and so on, which can crush the raw material into small particles with size 3~5mm.

Feature

●Waste timber grinder Machine can drive by Motor,Diesel,Gasoline Engine.

●Offering 220V and 380V,Accept Customized Voltage.

●Simple and Automatic Operation.

●Easy Maintainance.

●It can be combined wheels, no limitation on the places.

●It realizes the perfect combination on the chipping and crushing.

●Hammer Mill can equipped with airlock, cyclone ,offering customized design.


Motor Drive	Diesel Engine Drive	Hammer Mill with Cyclone

Technical Parameter

Model	FS-500	FS-600	FS-800	FS-1000	FS-1300	FS-1500
Feeding Size(mm)	500*280	600*300	800*350	1000*450	1300*450	1500*450
Crushing chamber size(mm)	500*500	600*600	800*700	1000*800	1300*800	1500*800
No. of hammer(pcs)	30/20	40/30	50/30	66/48	72/54	90/72
Hammer size(mm)	1806010	1806010	2306010	2306010	2306010	2306010
Power(Kw)	22-30	30-37	37-45	55-75	75-90	90-110
Fan power(Kw)	without	without	7.5	11	15	15
Capacity (Kg/h)	500-800	800-1200	1500-2000	2000-3000	3000-4000	4000-6000

Remark

We can customize all kinds of high quality wood hammer according to your requirements!

Including diesel wood hammer, movable wood hammer, wood log wood chipper etc.

Working Principle

After being delivered into the crushing chamber, raw material is beaten and crushed by high speed rotating blades. Under centrifugal force the cracked material is crushed quickly due to continuous squeezing, crushing, beating, scrubbing by hammer mill blades. Under rotor centrifugal and fan suction force, crushed particles are discharged through sieve holes while those cannot get through sieve hole will repeat above hammering process till they are discharged through sieve

image008(001)

The benefits of our Waste Timber Grinder

●Suitable for small scale wood pellet production.

●Mesh size can be adjusted from 1.8-10mm.

●Diesel engine biomass hammer mill is suitable for areas short of electricity or areas inconvenient to connect electricity.

●It is widely used for grinding for maize, grain sorghum, rice bran, rice straw, vine, maize straw, sorghum stalk. beanstalk, wheat straw etc.

●Belt conveying, compact structure, easy to operate, all of all rotors pass an accurate dynamic balancing test, less vibration during running.

●It is with aspiration system, high output, less noise and easy to operate.

●To ensure security, the feed inlet of this machine adopts self auction design to avoid serious damage to operators.

image010(001)

Hammer Mill with Cyclone

Application

Used for crushing wood material at home and farm or in small scale wood processing factories. The raw materials the machine can process are : wood branches, wood barks, wood cuttings, crop stalks, rice husk, cotton stalks, coconut shells, sunflower husks, wheat straw, rice straw, palm kernel shells, haulm, peanut straw, sweet potato straw and so on. The final products of the hammer mill, fine and uniform, have a wide application for biomass fuel pellets, animal bedding and other wood product production.

image012(001)
