Sawdust making machine can be used to crush wood logs, wood branch, wood chips etc. into wood sawdust for paper making, edible mushroom, BBQ charcoal, shaving board and sawdust board processing and other industrial production.
Main Features
●Can process logs, wood sticks, tree branches and waste wood material into sawdust one time.
●The size of sawdust can be adjusted by changing screen.
●This sawdust making machine can be driven with both electric motor and diesel engine according to customer's needs.
●The Sawdust making machine's color can be customized as client's requirement.
●Widely used in paper making, edible mushroom, mechanism charcoal, shaving board, sawdust board, high density board and other industrial production in the preparation section.
Motor Drive Sawdust Making Machine
Engine Drive Sawdust Making Machine
Sawdust Making Machine Technical Index
|
Model No. |
H420 |
H600 |
H800 |
H1000 |
|
Disc Dia.(mm) |
400 |
600 |
800 |
1000 |
|
Speed(r/min) |
2600 |
2600 |
2300 |
2000 |
|
Knives (pcs) |
4 |
4 |
6 |
4-6 |
|
Feeding size (mm) |
150*180 |
200*200 |
250*300 |
300*300 |
|
Output(kg/h) |
300-600 |
800-1000 |
1500-2000 |
2000-3000 |
|
Motor power(kw) |
7.5-11 |
18.5-22 |
30 |
75+7.5 |
|
Weight(kg) |
350 |
400 |
1500 |
1800 |
|
Dimension( m) |
1.2*0.85*0.9 |
1.5*1.0*1.1 |
2.1*1.1*1.3 |
2.6*1.1*1.5 |
Structures
Sawdust making machine is composed of machine body, knife chipping part, chips re-crush part and sieving part ,etc It combines both chipping and crushing in one machine, can make sawdust in one passage, no need to use wood chipper for preprocessing of wood logs. To ensure security, the feed inlet of this crushing equipment adopts self-sction design to avoid serious damage to operators.
Raw Materials
The raw material that can be wood logs,wood branches,bamboo,couch grass,straw and others agriculture material etc.
Usage of Sawdust
●1.The base raw material for cultivated edible fungus/Edible mushroom cultivation;
●2.Production of biomass fuel pellet/wood charcoal:
For Civil heating burning ,industrial boilers ,replace of coal, heavy oil, natural gas
●3.Medium,small particleboard and fibreboard production:
Particleboard, plywood, high density board, sawdust board, MDF, etc.
●4.Mosquito-repellent incense making;
●5.Paper making raw material.
Final Product
●Can be used as raw material for mushroom cultivation.
●Can be used for making pellets for bio fuels or animal feed.
●Can be crusher used for making briquette charcoal .
Working Principles
1). This machine is composed by host body, middle body and lower body such three parts;
2). Crushing cutter includes 7-shape cutter, 1-shape cutter and centrifugal cutters.
3). Auxiliary equipments include fan, dust collector and powder collector, etc.
4). The crushing processing will be coarse crushing, fine crushing and high speed centrifugal crushing. Motor drives crushing rotor to do high speed rotation, which can make machine produces high speed airflow. And then high speed airflow produces high strength impact force, compression force, cutting force and friction force for raw materials. In this way, the machine achieves special crushing function.
5). The crushed materials enters analyzer under the high speed airflow force. At the same time, the materials also get both rotor centrifugal force effect and airflow centripetal force.
Package
1.Machines will be packed in standard and quantities boxes ,the production will have a safe and complete journey from our factory to your place.
2.Packaging details standard export wooden case or in container.
Shipping
1.We will serve your shipping method about ocean transport ,air lift ,freights and so on.
2.The delivery time is usually 7-15 working days upon receipt of your payment.
